Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering

  • Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering
  • Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering
  • Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering
  • Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering
  • Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering
مكان المنشأ شنغهاي، الصين
اسم العلامة التجارية TOBO
إصدار الشهادات ISO/TUV/SGS
رقم الموديل أنابيب نحاس ونيكل
الحد الأدنى لكمية 1 قطعة
الأسعار قابل للتفاوض
تفاصيل التغليف حزمة الشحن القياسية
وقت التسليم 15-30 أيام العمل
شروط الدفع / تي تي، ويسترن يونيون
القدرة على العرض 10 طن / شهر
تفاصيل المنتج
المنتج nanme المصنع مباشرة CuNi 70/30 أنابيب النحاس والنيكل غير الملحومة ASME SB466 فئة 150 الشفاه اسم المنتج أنابيب نحاس ونيكل
لون لون النحاس الكلمة الرئيسية وصلات مواسير نحاسية
مواصفة حسب الطلب التطبيقات الهندسة البحرية، محطات تحلية المياه، المبادلات الحرارية، النفط والغاز البحري
القطر الخارجي حسب الطلب سطح مصقول
ليونة جيد استمارة ماسورة
صلابة 1/16 صلب، 1-8 صلب طرق الانضمام اللحام، اللحام، اللحام
شكل مربع مستدير مسحوق أم لا لا مسحوق
ضمان 1 سنة تكوين الخامات سبائك النحاس والنيكل (عادة 90/10 أو 70/30 Cu/Ni)
رمز الرأس دائري التعبئة البليت ، حالة خشبية
إبراز

CuNi 70/30 seamless nickel copper pipe

,

ASME SB466 nickel copper pipe

,

Class 150 flanges copper nickel pipe
اترك رسالة
منتوج وصف

Factory Direct CuNi 70/30 Seamless Nickel Copper Pipe ASME SB466 Class 150 Flanges



1.Product Description

Copper-nickel pipe is a seamless or welded tubular product made from copper-nickel alloy, primarily composed of copper (Cu) and nickel (Ni), with minor additions of iron (Fe) and manganese (Mn) to enhance mechanical properties and corrosion resistance. The most common grades are 90/10 (CuNi 90/10, UNS C70600) and 70/30 (CuNi 70/30, UNS C71500). These pipes are manufactured according to international standards such as ASTM B466, B467, B111, and EN 12451, offering excellent dimensional accuracy, uniform wall thickness, and superior surface quality. They are available in a wide range of diameters and schedules to meet diverse engineering requirements.


2. Product Applications

Copper-nickel pipes are widely used in marine engineering, offshore oil and gas platforms, shipbuilding (hull piping, cooling water systems, fire protection systems), seawater desalination plants, power generation stations (condenser and heat exchanger tubes), chemical processing industries, and coastal infrastructure. They are the preferred material for conveying seawater, brine, and other corrosive fluids, as well as for high-temperature steam and hydraulic systems requiring reliable anti-fouling and biofouling resistance.



3. Product Advantages

  • Superior corrosion resistance – Exceptional resistance to seawater, brackish water, and chloride-induced pitting, stress corrosion cracking, and erosion-corrosion.

  • Excellent biofouling resistance – Naturally inhibits marine organism adhesion, reducing maintenance and cleaning frequency.

  • High strength and ductility – Good mechanical properties at both ambient and elevated temperatures, with easy bending, flanging, and welding.

  • Long service life – Proven track record of 30+ years in marine environments with minimal degradation.

  • Low magnetic permeability – Suitable for applications where non-magnetic materials are required.

  • Good thermal conductivity – Efficient heat transfer performance for heat exchanger applications.

  • Fabrication friendly – Compatible with standard welding, brazing, and soldering techniques; readily machinable.

​Factory Direct Seamless CuNi 70/30 Nickel Copper Pipe ASME SB466 Class 150 for Marine Engineering

4.Key Technical Parameters



Parameter 90/10 (C70600) 70/30 (C71500)
Chemical Composition Cu: 88.5–90.5%, Ni: 9.0–11.0%, Fe: 1.0–1.8%, Mn: ≤1.0% Cu: 68.5–70.5%, Ni: 29.0–31.0%, Fe: 0.4–1.0%, Mn: ≤1.0%
Density 8.94 g/cm³ 8.94 g/cm³
Melting Range 1,100–1,150°C 1,170–1,240°C
Tensile Strength (min) 290 MPa 485 MPa
Yield Strength (0.2% offset, min) 105 MPa 175 MPa
Elongation (min) 30% (in 50 mm) 30% (in 50 mm)
Hardness (Rockwell B) 65–80 HRB 75–90 HRB
Electrical Conductivity ~7% IACS ~4.5% IACS
Thermal Conductivity ~45 W/(m·K) at 20°C ~29 W/(m·K) at 20°C
Coefficient of Thermal Expansion ~16.2 × 10⁻⁶ /°C (20–300°C) ~15.8 × 10⁻⁶ /°C (20–300°C)
Operating Temperature Range –200°C to +300°C –200°C to +350°C
Standard Dimensions OD: 6.0–400.0 mm; Wall thickness: 0.5–30.0 mm; Length: up to 12 m (or as required)
Manufacturing Standards ASTM B466/B467/B111, EN 12451, JIS H3300, etc.
Product Forms Seamless or welded (straight or coiled)



FAQ

1. Are you trading company or manufacturer ? We are manufacturer ,You can see the certification.

2.How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

3. Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but need pay the cost of freight.

4. What is your terms of payment ? Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
